The 10mm batten lengths have been selected for maximum ease of use. When fitted with our standard 10mm Inner Crescent T10C (BS-BC1002) and a 10mm Tie In Outer T10T (BS-BC1004), the finished batten length will suit the majority of class rules without the need for cutting.
The endcaps when used together add 15mm / 0.6” to the overall batten length. Please use the guide to help select the correct batten length for your needs. The finished lengths shown represent the standard batten fitted with a 10mm Crescent Inner and 10mm Tie In Outer end caps.
Part No. | Description | Original Length | Finished Length |
BS-012045L | 450mm x 10mm Light Dinghy Leech Batten | 450mm / 17.7'' | 465mm / 18.3'' |
BS-012049L | 485mm x 10mm Light Dinghy Leech Batten | 485mm / 19.1'' | 500mm / 19.7'' |
BS-012059L | 590mm x 10mm Light Dinghy Leech Batten | 590mm / 23.2'' | 605mm / 23.8'' |
BS-012067L | 670mm x 10mm Light Dinghy Leech Batten | 670mm / 26.4'' | 685mm / 27.0'' |
BS-012075L | 745mm x 10mm Light Dinghy Leech Batten | 745mm / 29.4'' | 760mm / 30.0'' |
BS-012082L | 820mm x 10mm Light Dinghy Leech Batten | 820mm / 32.3'' | 835mm / 32.8'' |
BS-012090L | 900mm x 10mm Light Dinghy Leech Batten | 900mm / 35.4'' | 915mm / 36.0'' |
BS-012099L | 985mm x 10mm Light Dinghy Leech Batten | 985mm / 38.8'' | 1000mm / 39.4'' |
BS-012105L | 1050mm x 10mm Light Dinghy Leech Batten | 1050mm / 41.3'' | 1065mm / 41.9'' |
